Specifications and Price
Change model
-
Extreme Red
-
Extreme Red
-
Extreme Red
Specifications
CRF110F 2025
Engine
-
Bore × Stroke (mm)
50.0mm x 55.6mm
-
Carburation
Fuel-injection, 19mm throttle bore
-
Compression Ratio
9.0:1
-
Engine Displacement (cc)
109cc
-
Engine Type
Air-cooled single-cylinder four-stroke
Wheels
-
Brakes Front
Drum
-
Brakes Rear
Drum
-
Suspension Front
31.0mm telescopic fork; 10cm of travel
-
Suspension Rear
Single-shock; 9.5cm of travel
-
Tyre Size Front
70/100-14
-
Tyre Size Rear
80/100-12
Dimensions and Weights
-
Caster Angle
25°10'
-
Fuel Tank Capacity (Litres)
4.55 Litres
-
Ground Clearance (mm)
17cm
-
Kerb Weight (kg)
77kg
-
Seat Height (mm)
657mm
-
Trail (mm)
53mm
-
Weight (kg)
77kg
-
Wheelbase (mm)
106.5cm
Transmission
-
Clutch Operation
Automatic
-
Final Drive
#420 Chain
-
Gearbox
Four-speed with automatic clutch
Instruments and Electrics
-
Ignition System
Full Transistorized
CRF110F 2024
£2,699.00
Engine
-
Bore × Stroke (mm)
50.0mm x 55.6mm
-
Carburation
Fuel-injection, 19mm throttle bore
-
Compression Ratio
9.0:1
-
Engine Displacement (cc)
109cc
-
Engine Type
Air-cooled single-cylinder four-stroke
Wheels
-
Brakes Front
Drum
-
Brakes Rear
Drum
-
Suspension Front
31.0mm telescopic fork; 10cm of travel
-
Suspension Rear
Single-shock; 9.5cm of travel
-
Tyre Size Front
70/100-14
-
Tyre Size Rear
80/100-12
Dimensions and Weights
-
Caster Angle
25°10'
-
Fuel Tank Capacity (Litres)
4.55 Litres
-
Ground Clearance (mm)
17cm
-
Kerb Weight (kg)
77kg
-
Seat Height (mm)
657mm
-
Trail (mm)
53mm
-
Weight (kg)
77kg
-
Wheelbase (mm)
106.5cm
Transmission
-
Clutch Operation
Automatic
-
Final Drive
#420 Chain
-
Gearbox
Four-speed with automatic clutch
Instruments and Electrics
-
Ignition System
Full Transistorized
CRF110F 2022
£2,499.00
Engine
-
Bore × Stroke (mm)
50.0mm x 55.6mm
-
Carburation
Fuel-injection, 19mm throttle bore
-
Compression Ratio
9.0:1
-
Engine Displacement (cc)
109cc
-
Engine Type
Air-cooled single-cylinder four-stroke
Wheels
-
Brakes Front
Drum
-
Brakes Rear
Drum
-
Suspension Front
31.0mm telescopic fork; 10cm of travel
-
Suspension Rear
Single-shock; 9.5cm of travel
-
Tyre Size Front
70/100-14
-
Tyre Size Rear
80/100-12
Dimensions and Weights
-
Caster Angle
25°10'
-
Fuel Tank Capacity (Litres)
4.55 Litres
-
Ground Clearance (mm)
17cm
-
Seat Height (mm)
65cm
-
Trail (mm)
53mm
-
Weight (kg)
77kg
-
Wheelbase (mm)
106.5cm
Transmission
-
Clutch Operation
Automatic
-
Final Drive
#420 Chain
-
Gearbox
Four-speed with automatic clutch
Instruments and Electrics
-
Ignition System
Full Transistorized
