Specifications and Price
Change model
-
Pearl Dask Yellow
-
Matte Fresco Brown
-
Matte Laurel Green Metallic
-
Matte Gunpowder Black Metallic
-
Candy Caribbean Blue Sea
-
Matte Laurel Green Metallic
-
Matte Gunpowder Black Metallic
-
Candy Energy Orange
Specifications
Key Specs
-
Clutch
Wet multiplate, Assisted slipper clutch
-
Headlights
LED
-
Seat Height (mm)
790mm
-
Emergency Stop Signal
Yes
-
Instruments
LCD Meter with Speedometer, Dual Trip Meters, Fuel Level and Consumption Gauge, Clock, Gear position, Shift UP Indicator
Engine
-
Bore × Stroke (mm)
67 x 66.8
-
Carburation
PGM-FI electronic fuel injection
-
Compression Ratio
10.7:1
-
Engine Displacement (cc)
471cc
-
Engine Type
Liquid-cooled DOHC 4-stroke 4-valve two-cylinder
-
Max. Power Output
34kW @ 8500rpm
-
Max. Torque
43.3Nm @ 6000rpm
-
Starter
Electric
-
C02 Emissions (g/km)
86 g/km
-
Oil Capacity (Litres)
3.2L
Wheels
-
ABS System
2 channel
-
Brakes Front
Single 310mm floating disc, 2 piston calipers
-
Brakes Rear
Single 240mm disc, 1 piston caliper
-
Suspension Front
Telescopic 41mm Upright forks, 150mm travel
-
Suspension Rear
Twin shock with 45mm round pipe swingarm, 5-step pre-load adjustment
-
Tyre Size Front
110/80R19M/C 59H
-
Tyre Size Rear
150/70R17M/C 69H
-
Wheels Front
Cast Aluminium
-
Wheels Rear
Cast Aluminium
Dimensions and Weights
-
Battery Capacity (VAh)
12V 7Ah
-
Caster Angle
27°
-
Dimensions (L×W×H) (mm)
2175mm x 830mm x 1135mm
-
Frame type
Steel Diamond
-
Fuel Tank Capacity (Litres)
12L
-
Fuel Consumption
27.7 km/l
-
Ground Clearance (mm)
155mm
-
Kerb Weight (kg)
191 kg
-
Seat Height (mm)
790mm
-
Trail (mm)
108mm
-
Wheelbase (mm)
1484mm
-
Turning Radius
2.7 m
-
Noise Level
Lwot- 76.1dB; Lurban - 72.9 dB
Transmission
-
Clutch
Wet multiplate, Assisted slipper clutch
-
Final Drive
Chain
-
Transmission Type
6 Speed Manual Transmission
Instruments and Electrics
-
Headlights
LED
-
12v Socket
Optional
-
Instruments
LCD Meter with Speedometer, Dual Trip Meters, Fuel Level and Consumption Gauge, Clock, Gear position, Shift UP Indicator
-
Tail Light
LED
-
Emergency Stop Signal
Yes
