Specifications and Price
Specifications
Key Features
-
Connectivity
Honda RoadSync
Engine
-
Bore × Stroke (mm)
67mm x 46mm
-
Carburation
PGM-FI electronic fuel injection
-
Compression Ratio
11.6:1
-
Engine Displacement (cc)
649cc
-
Engine Type
Liquid-cooled 4-stroke 16-valve DOHC inline-4
-
Max. Power Output
70kW / 12,000rpm
-
Max. Torque
63Nm / 9,500rpm
-
Starter
Electric
-
C02 Emissions (g/km)
112
Wheels
-
Brakes Front
310 mm x 4.5 mm double disc with four piston caliper
-
Brakes Rear
240 mm x 5 mm disc with single piston caliper
-
Suspension Front
41mm Showa Separate Function front Fork Big Piston (SFF-BP) USD forks
-
Suspension Rear
Monoshock damper with 10 stage pre-load adjuster, Aluminium Cast swingarm, 43.5mm stroke
-
Tyre Size Front
120/70ZR17M/C
-
Tyre Size Rear
180/55ZR17M/C
-
Wheels Front
17M/C X MT3.50 Hollow section 5-Spoke Cast Aluminium
-
Wheels Rear
17M/C X MT5.50 Hollow section 5-Spoke Cast Aluminium
Dimensions and Weights
-
Battery Capacity (VAh)
YTZ10/FTZ10S 9.1Ah
-
Caster Angle
25.5°
-
Dimensions (L×W×H) (mm)
2,120mm X 750mm X 1,145mm
-
Frame type
Steel diamond
-
Fuel Tank Capacity (Litres)
15.4L
-
Ground Clearance (mm)
130mm
-
Kerb Weight (kg)
211kg
-
Seat Height (mm)
810mm
-
Wheelbase (mm)
1,450mm
Transmission
-
Clutch
Wet multiplate, A.S.clutch
-
Final Drive
Chain
-
Gearbox
6-speed
Instruments and Electrics
-
Headlights
LED
-
Ignition System
Full transisterized
-
Instruments
5-inch full colour TFT screen includes Honda RoadSync, Digital speedometer, digital bar graph tachometer, dual trip meter, digital bar graph fuel gauge, gear position and upshift indicator, digital clock
-
Tail Light
LED
-
Connectivity
Honda RoadSync
