Specifications and Price
Change model
-
Pearl Falcon Grey
-
Matte Pearl Pacific Blue
-
Matte Coal Black Metallic Sport
-
Matte Pearl Cool White Sport
-
Pearl Falcon Grey
-
Matte Pearl Pacific Blue
-
Coal Black
-
Hyper Red
Specifications
Key Specs
-
Clutch
Automatic; centrifugal
-
Headlights
LED
-
Seat Height (mm)
799mm
-
Instruments
LCD presents all warning lights – including Smart Key, HSTC/ABS and Idling Stop operation – neatly around a central digital speedo/odometer display.
Engine
-
Bore × Stroke (mm)
53.5 x 55.4
-
Carburation
PGM-FI electronic fuel injection
-
Compression Ratio
11.5:1
-
Engine Displacement (cc)
124.5cc
-
Engine Type
Liquid-cooled, 4-stroke SOHC
-
Max. Power Output
9.6kW/8,250rpm
-
Max. Torque
11.4Nm/6,500rpm
-
Starter
Electric
-
Oil Capacity (Litres)
0.9L
Wheels
-
ABS System
2 Channel
-
Brakes Front
240mm disc, 2 piston caliper
-
Brakes Rear
240mm disc, single piston caliper
-
Suspension Front
Telescopic Φ33
-
Suspension Rear
Dual-damper unit swing arm
-
Tyre Size Front
100/80-16 inch
-
Tyre Size Rear
120/80-16 inch
-
Wheels Front
16M/C x MT2.50
-
Wheels Rear
16M/C x MT2.75
Dimensions and Weights
-
Battery Capacity (VAh)
YTZ8V 7Ah MF
-
Caster Angle
26°
-
Dimensions (L×W×H) (mm)
2,090mm x 730mm x 1,130mm
-
Frame type
Tubular Steel Underbone
-
Fuel Tank Capacity (Litres)
7L
-
Fuel Consumption
45.5km/litre
-
Ground Clearance (mm)
142mm
-
Kerb Weight (kg)
137kg
-
Seat Height (mm)
799mm
-
Trail (mm)
85mm
-
Wheelbase (mm)
1,353mm
Transmission
-
Clutch
Automatic; centrifugal
-
Final Drive
V-Belt
-
Transmission Type
CVT
Instruments and Electrics
-
Headlights
LED
-
Instruments
LCD presents all warning lights – including Smart Key, HSTC/ABS and Idling Stop operation – neatly around a central digital speedo/odometer display.
-
Tail Light
LED
-
USB Socket
Yes
Key Specs
-
Clutch
Automatic; centrifugal
-
Headlights
LED
-
Seat Height (mm)
799mm
-
Instruments
LCD presents all warning lights – including Smart Key, HSTC/ABS and Idling Stop operation – neatly around a central digital speedo/odometer display.
Engine
-
Bore × Stroke (mm)
53.5 x 55.4
-
Carburation
PGM-FI electronic fuel injection
-
Compression Ratio
11.5:1
-
Engine Displacement (cc)
124.5cc
-
Engine Type
Liquid-cooled, 4-stroke SOHC
-
Max. Power Output
9.6kW/8,250rpm
-
Max. Torque
11.4Nm/6,500rpm
-
Starter
Electric
-
Oil Capacity (Litres)
0.9L
Wheels
-
ABS System
2 Channel
-
Brakes Front
240mm disc, 2 piston caliper
-
Brakes Rear
240mm disc, single piston caliper
-
Suspension Front
Telescopic Φ33
-
Suspension Rear
Dual-damper unit swing arm
-
Tyre Size Front
100/80-16 inch
-
Tyre Size Rear
120/80-16 inch
-
Wheels Front
16M/C x MT2.50
-
Wheels Rear
16M/C x MT2.75
Dimensions and Weights
-
Battery Capacity (VAh)
YTZ8V 7Ah MF
-
Caster Angle
26°
-
Dimensions (L×W×H) (mm)
2,085mm x 740mm x 1,129mm
-
Frame type
Tubular Steel Underbone
-
Fuel Tank Capacity (Litres)
7L
-
Fuel Consumption
44.6km/litre
-
Ground Clearance (mm)
142mm
-
Kerb Weight (kg)
136.5kg
-
Seat Height (mm)
799mm
-
Trail (mm)
85mm
-
Wheelbase (mm)
1,353mm
Transmission
-
Clutch
Automatic; centrifugal
-
Final Drive
V-Belt
-
Transmission Type
CVT
Instruments and Electrics
-
Headlights
LED
-
Instruments
LCD presents all warning lights – including Smart Key, HSTC/ABS and Idling Stop operation – neatly around a central digital speedo/odometer display.
-
Tail Light
LED
-
USB Socket
Yes
